Description
The AND Static Eliminator generates ions and can be used for the elimination of static charges with little or no reverse charge is induced by irradiated ions because of its excellent ion polarity balance.
Easily remove static from your high-precision weighing applications with our AD-1683 static eliminator.
Easily remove static from your high-precision weighing applications with our AD-1683 static eliminator.
- Can be easily and safely installed because they require no high-voltage wiring.
- Static charge eliminator generates ions and can be used for elimination of static charges
- Little or no reverse charge is induced by irradiated ions because of its excellent ion polarity balance.
Easily remove static from your high-precision weighing applications with our AD-1683 static eliminator.
| Static Eliminating Method | DC corona discharge (Bipolar) | ||||||||||
| Elimination Range | Distance:Approz. 10 cm to 30 cm from the electode. Area: 30x30 cm from the electode. (See Figure 2.) |
||||||||||
| Elimination Performance | When Charged 5kV:
|
||||||||||
| Ambient Temperatureand Humidity Ozone Concentration | 0°C to 40°C, 80% RH or less Positive discharge pin: 0.07PPM Negative discharge pin: 0.25PPM (Measured at a distance of 1cm from each discharge pin.) |
||||||||||
| Power Supply | AC adapter. Please confirm that the AC adapter type is correct for your local voltage and receptacle type. | ||||||||||
| Power Consumption | Approx. 1.5 VA | ||||||||||
| Discharge Electrode Pin | Tungsten (0.9 x 17mm), Life Approx. 10000hrs | ||||||||||
| Mass | Approx. 300g (including the stand) |
